| Input | Rated Input Voltage | 100VAC-240VAC | Rated Input Frequency | 50/60Hz | |
|
|
Input Voltage Range | 90VAC-264VAC | Inrush Current | 30A Max | |
|
|
Input Current | 0.2A Max | Leakage Current | 0.25mA Max | |
|
|
Efficiency | CEC ERP GEMS | |||
| Output | Output Voltage | DC 1.2-36V | |||
|
|
Output Voltage Regulation | ±5% constant Voltage Mode | |||
|
|
Output Current Regulation | ±5% constant Current Mode | |||
|
|
Output Current | 0.01A-1.6A | |||
|
|
Ripple and Noise | 120mVp-p max @20MHz Bandwidth 47uF Ele.Cap.+0.1uF Cer.Cap. | |||
|
|
Maximal Power | 6W max | |||
|
|
Turn-On Delay Time | Less than 3S Typical At Full Load | |||
|
|
Hold-up Time | 10ms Typical At Full Load | |||
|
|
Protection | Over-current Protection; short-circuit Protection; ver-voltage Protection | |||
|
|
DC Cable | UL2468 UL2464 UL1185 SPT | |||
| The certificate | UL GS PSE CE CB SAA FCC LVD CCC EMC EMF C-TICK RCM BSMI | ||||
| standard | EMC | CISPR22/EN55022 CISPR24/EN55024 EN 61000 FCC Part 15 CISPR14/EN55014-1 EN55014-2 EN62233 | |||
|
|
Safety | IEC/EN AS/NZS 60950 IEC/EN 60335 UL60950 J60950 J60335 GB4943-2011 CNS14336 | |||
| Environmental | Operation Temperature | 0℃ to 40℃ ambient | |||
|
|
Storage Temperature | .-10℃ to 75℃ | |||
|
|
High-Reliability: MTBF > 20000 Hours under 25℃ | ||||
| Weight | 70g | ||||
